It is lubricated and has excellent durability.

As a large capacity valve, can be used for Ø80~Ø250 cylinders.

There are a variety of options for the push, lock and coil parts of the manual operation section, with a variety of lead lengths.

Item \ conversion method even closed

Center exhaust

Central pressure

center

Oil port size PT1/2 (G1/2, NPT1/2)

Fluid compressed air

Working pressure 1.5~9.0 bar 2.0~9.0 bar

Instantaneous flow 3500 L/min (5 bar) 2700 L/min (5 bar)

Effective area (Cv) 65.0 ㎟ ㎟ 50.0 (3.5) (2.8)

Ambient and fluid temperature 5~60℃

Response time (5bar) Under 30ms Under 40ms

Large operating frequency 2 cycles per second 1 cycle per second

No lubrication required (use ISO VG32# for lubrication)

Manual operation button (standard), rotating rod (optional)

Rated coil voltage AC220, AC110, AC24(50-60 Hz)/DC24V, DC12V

Allow voltage fluctuation ±10% of rated voltage

F corresponds to coil edge type

Apparent power AC 4.5VA (60Hz)

Power consumption DC 2.5W
